Revit二次开发API示例 ExternalResourceUIServer 通过外部资源服务器，使用户能够使用来自外部的材质、家具和设备等资源。
659
2024/09/29
应用程序：ExternalResourceUIServer
Revit 平台：所有
Revit 版本：2015.0
首次发布版本：2015.0
编程语言：C#
技能水平：中等
类别：数据交换
类型：外部应用程序
主题：一个外部资源 UI 服务器类
摘要：
这是一个 IExternalResourceUIServer 的实现类，用于支持 ExternalResourceDBServer 项目中的 SampleExternalResourceServer，并提供消息和其他 UI。
相关类：
Autodesk.Revit.UI.IExternalApplication
Autodesk.Revit.UI.IExternalResourceUIServer
项目文件：
Application.cs
包含 UIServerApplication 类，该类继承自接口 IExternalpplication 并实现 OnStartup 和 OnShutdown 方法。在 OnStartup 方法中，样例外部资源 UI 服务器已经被注册到了 Revit 中。
SampleExternalResourceUIServer.cs
含有 SampleExternalResourceUIServer 类，该类是 IExternalResourceUIServer 接口的一个实现。
说明：
此示例提供以下功能：
- 为 SampleExternalResourceDBServer 添加 UI（消息框）。
- 显示来自 SampleExternalResourceDBServer 加载的主题演讲数据的加载结果消息。
- 显示从 SampleExternalResourceDBServer 链接的 Revit 模型的加载结果消息。
- 如果最终用户在浏览 SampleExternalResourceDBServer 的主题演讲或 Revit 链接资源时发生故障，则显示警告。
- 注意：实现 IExternalResourceUIServer 为你的 IExternalResourceServer 提供 UI 是高度推荐的，但实际上并非必需。要说明这一点，请尝试安装和使用带有和不带有 SampleExternalResourceUIServer 的 SampleExternalResourceDBServer。DB 服务器应该可以正常运行，但是在没有 UI 服务器的情况下，没有办法知道 Revit 和 DB 服务器之间的交互是否完全成功，也没有办法确定任何错误的原因。
指导：
请按照 ExternalResourceDBServer 的说明进行操作。
1. 加载主题演讲数据时的 UI
期望的结果: 当用户选择一个主题演讲数据资源时，应该会出现下面所示的消息对话框：
2. 链接一个 Revit 模型时的 UI
期望的结果: 当用户从 SampleExternalResourceDBServer 中选择一个要链接到 Revit 的 Revit 模型时，应该会出现下面所示的消息对话框：
源代码：
完整的源代码请加入QQ群649037449，在群文件中下载RevitSDK.exe，解压后在文件夹中搜索本文中应用程序名称即可获得完整源码
Application.cs
//
// (C) Copyright 2003-2019 by Autodesk, Inc. All rights reserved.
//
// Permission to use, copy, modify, and distribute this software in
// object code form for any purpose and without fee is hereby granted
// provided that the above copyright notice appears in all copies and
// that both that copyright notice and the limited warranty and
// restricted rights notice below appear in all supporting
// documentation.
//
// AUTODESK PROVIDES THIS PROGRAM 'AS IS' AND WITH ALL ITS FAULTS.
// AUTODESK SPECIFICALLY DISCLAIMS ANY IMPLIED WARRANTY OF
// MERCHANTABILITY OR FITNESS FOR A PARTICULAR USE. AUTODESK, INC.
// DOES NOT WARRANT THAT THE OPERATION OF THE PROGRAM WILL BE
// UNINTERRUPTED OR ERROR FREE.
//
// Use, duplication, or disclosure by the U.S. Government is subject to
// restrictions set forth in FAR 52.227-19 (Commercial Computer
// Software - Restricted Rights) and DFAR 252.227-7013(c)(1)(ii)
// (Rights in Technical Data and Computer Software), as applicable.
using System;
using System.Collections.Generic;
using System.Text;
using System.Windows.Forms;
using System.IO;
using Autodesk;
using Autodesk.Revit;
using Autodesk.Revit.DB;
using Autodesk.Revit.DB.ExternalService;
using Autodesk.Revit.UI;
using Autodesk.Revit.ApplicationServices;
namespace Revit.SDK.Samples.ExternalResourceUIServer.CS
{
/// <summary>
/// <para>Implements the Revit add-in interface IExternalApplication.</para>
/// <para>An IExternalResourceUIServer can be registered at any time during a Revit session.
/// However, the most straightforward approach is to register during start-up, in the
/// OnStartUp method of a Revit external application. This should be a (UI-level)
/// IExternalApplication, and NOT an IExternalDBApplication.</para>
/// </summary>
class UIServerApplication : IExternalApplication
{
#region IExternalApplication Members
/// <summary>
/// Registers an instance of a SampleExternalResourceUIServer with the ExternalService
/// of type ExternalResourceUIService.
/// </summary>
/// <param name="application">An object that is passed to the external application
/// which contains the controlled application.</param>
/// <returns>Return the status of the external application. A result of Succeeded
/// means that the external application was able to register the IExternalResourceUIServer.
/// </returns>
public Result OnStartup(UIControlledApplication application)
{
ExternalService externalResourceUIService = ExternalServiceRegistry.GetService(ExternalServices.BuiltInExternalServices.ExternalResourceUIService);
if (externalResourceUIService == null)
return Result.Failed;
// Create an instance of your IExternalResourceUIServer and register it with the ExternalResourceUIService.
IExternalResourceUIServer sampleUIServer = new SampleExternalResourceUIServer();
externalResourceUIService.AddServer(sampleUIServer);
return Result.Succeeded;
}
/// <summary>
/// Implements the OnShutdown event.
/// <para>The server implementer may wish to perform clean-up tasks here. However, in the
/// simplest case, no server-related code is required, and the server will be
/// destroyed as Revit shuts down.</para>
/// </summary>
/// <param name="application">An object that is passed to the external application
/// which contains the controlled application.</param>
/// <returns>Return the status of the external application.</returns>
public Result OnShutdown(UIControlledApplication application)
{
return Result.Succeeded;
}
#endregion IExternalApplication Members
}
}
SampleExternalResourceUIServer.cs
//
// (C) Copyright 2003-2019 by Autodesk, Inc.
//
// Permission to use, copy, modify, and distribute this software in
// object code form for any purpose and without fee is hereby granted,
// provided that the above copyright notice appears in all copies and
// that both that copyright notice and the limited warranty and
// restricted rights notice below appear in all supporting
// documentation.
//
// AUTODESK PROVIDES THIS PROGRAM "AS IS" AND WITH ALL FAULTS.
// AUTODESK SPECIFICALLY DISCLAIMS ANY IMPLIED WARRANTY OF
// MERCHANTABILITY OR FITNESS FOR A PARTICULAR USE. AUTODESK, INC.
// DOES NOT WARRANT THAT THE OPERATION OF THE PROGRAM WILL BE
// UNINTERRUPTED OR ERROR FREE.
//
// Use, duplication, or disclosure by the U.S. Government is subject to
// restrictions set forth in FAR 52.227-19 (Commercial Computer
// Software - Restricted Rights) and DFAR 252.227-7013(c)(1)(ii)
// (Rights in Technical Data and Computer Software), as applicable.
//
using System;
using System.Collections.Generic;
using System.Linq;
using System.Text;
using Autodesk.Revit;
using Autodesk.Revit.DB;
using Autodesk.Revit.DB.ExternalService;
using Autodesk.Revit.UI;
using Revit.SDK.Samples.ExternalResourceDBServer.CS;
namespace Revit.SDK.Samples.ExternalResourceUIServer.CS
{
class SampleExternalResourceUIServer : IExternalResourceUIServer
{
// Methods that must be implemented by a server for any of Revit's external services
#region IExternalServer Implementation
/// <summary>
/// Return the Id of the server.
/// </summary>
public System.Guid GetServerId()
{
return m_myServerId;
}
/// <summary>
/// Return the Id of the service that the server belongs to.
/// </summary>
public ExternalServiceId GetServiceId()
{
return ExternalServices.BuiltInExternalServices.ExternalResourceUIService;
}
/// <summary>
/// Return the server's name.
/// </summary>
public System.String GetName()
{
return "SDK Sample ExtRes UI Server";
}
/// <summary>
/// Return the server's vendor Id.
/// </summary>
public System.String GetVendorId()
{
return "ADSK";
}
/// <summary>
/// Return the description of the server.
/// </summary>
public System.String GetDescription()
{
return "Simple UI server for the Revit SDK sample external resource server";
}
#endregion IExternalServer Implementation
#region IExternalResourceUIServer Interface Implementation
/// <summary>
/// Return the Id of the related DB server.
/// </summary>
///
public System.Guid GetDBServerId()
{
return m_myDBServerId;
}
/// <summary>
/// Reports the results of loads from the DB server (SampleExternalResourceServer).
/// This method should be implemented to provide UI to communicate success or failure
/// of a particular external resource load operation to the user.
/// </summary>
/// <param name="doc">The Revit model into which the External Resource was loaded.
/// </param>
/// <param name="loadDataList">Contains a list of ExternalResourceLoadData with results
/// for all external resources loaded by the DB server. It is possible for the DB server
/// to have loaded more than one resource (for example, loading several linked files
/// when a host file is opened by the user).
/// </param>
public void HandleLoadResourceResults(Document doc, IList<ExternalResourceLoadData> loadDataList)
{
foreach (ExternalResourceLoadData data in loadDataList)
{
ExternalResourceType resourceType = data.ExternalResourceType;
// This message will be posted in a dialog box at the end of this method.
String myMessage = String.Empty;
ExternalResourceLoadContext loadContext = data.GetLoadContext();
ExternalResourceReference desiredRef = data.GetExternalResourceReference();
ExternalResourceReference currentlyLoadedRef = loadContext.GetCurrentlyLoadedReference();
LoadOperationType loadType = loadContext.LoadOperationType;
switch (loadType)
{
case LoadOperationType.Automatic:
myMessage = "This is an Automatic load operation. ";
break;
case LoadOperationType.Explicit:
myMessage = "This is an Explicit load operation. ";
break;
default:
myMessage = "There is no load type information!! ";
break;
}
bool bUnrecognizedStatus = false;
if (data.LoadStatus == ExternalResourceLoadStatus.ResourceAlreadyCurrent)
{
if (data.GetLoadContext().LoadOperationType == LoadOperationType.Explicit)
{
string resourcePath = currentlyLoadedRef.InSessionPath;
myMessage += "\n No new changes to load for link: " + resourcePath;
}
else
continue;
}
else if (data.LoadStatus == ExternalResourceLoadStatus.Uninitialized)
{
myMessage += "\n The load status is uninitialized - this generally shouldn't happen";
}
else if (data.LoadStatus == ExternalResourceLoadStatus.Failure)
{
myMessage += "\n The load failed and the reason is unknown.";
}
else if (data.LoadStatus == ExternalResourceLoadStatus.Success)
{
if (resourceType == ExternalResourceTypes.BuiltInExternalResourceTypes.KeynoteTable)
{
string resourcePath = data.GetExternalResourceReference().InSessionPath;
myMessage += "\n Version " + data.GetLoadContent().Version + " of keynote data \'" + resourcePath + "\' has been loaded successfully";
}
else if (resourceType == ExternalResourceTypes.BuiltInExternalResourceTypes.RevitLink)
{
string resourcePath = data.GetExternalResourceReference().InSessionPath;
LinkLoadContent ldrlc = (LinkLoadContent)(data.GetLoadContent());
string destinationPath = ModelPathUtils.ConvertModelPathToUserVisiblePath(ldrlc.GetLinkDataPath());
myMessage += "\n Version " + data.GetLoadContent().Version +
" of the file: " + resourcePath +
" has been downloaded into the cached folder: " + destinationPath +
" for this Revit Link.";
}
}
else
{
myMessage += "Unrecognized external resource load status.";
bUnrecognizedStatus = true;
}
if (!bUnrecognizedStatus && resourceType == ExternalResourceTypes.BuiltInExternalResourceTypes.RevitLink)
{
// For Revit links, the UI server can also obtain a RevitLinkLoadResult which contains detailed
// information about the status of the attempt to load the local copy of the link into Revit.
LinkLoadContent ldrlc = (LinkLoadContent)(data.GetLoadContent());
LinkLoadResult loadResult = ldrlc.GetLinkLoadResult();
if (loadResult != null)
{
myMessage += "\n LinkLoadResultType: " + loadResult.LoadResult.ToString("g");
}
}
System.Windows.Forms.MessageBox.Show(myMessage, "UI Server for SDK Sample External Resource Server");
}
}
/// <summary>
/// Use this method to report any problems that occurred while the user was browsing for External Resources.
/// Revit will call this method each time the end user browses to a new folder location, or selects an item
/// and clicks Open.
/// </summary>
public void HandleBrowseResult(ExternalResourceUIBrowseResultType resultType, string browsingItemPath)
{
if (resultType == ExternalResourceUIBrowseResultType.Success)
return;
String resultString = resultType.ToString("g");
// While executing its SetupBrowserData() method, the "DB server" - SampleExternalResourceServer - can store
// detailed information about browse failures that occurred (user not logged in, network down, etc.).
// Subsequently, when Revit calls this method, the details can be read from the DB server and reported to the user.
ExternalService externalResourceService = ExternalServiceRegistry.GetService(ExternalServices.BuiltInExternalServices.ExternalResourceService);
if (externalResourceService == null)
{
System.Windows.Forms.MessageBox.Show("External Resource Service unexpectedly not found.");
return;
}
SampleExternalResourceDBServer myDBServer = externalResourceService.GetServer(GetDBServerId()) as SampleExternalResourceDBServer;
if (myDBServer == null)
{
System.Windows.Forms.MessageBox.Show("Cannot get SampleExternalResourceDBServer from ExternalResourceService.");
return;
}
// ... Retrieve detailed failure information from SampleExternalResourceServer here.
String message = String.Format("The browse result for <{0}> was: <{1}>.", browsingItemPath, resultString);
System.Windows.Forms.MessageBox.Show(message);
}
#endregion IExternalResourceUIServer Interface Implementation
#region SampleExternalResourceUIServer Implementations
#endregion SampleExternalResourceUIServer Implementations
#region SampleExternalResourceUIServer Member Variables
private static Guid m_myServerId = new Guid("E9B6C194-62DE-4134-900D-BA8DF7AD33FA");
private static Guid m_myDBServerId = new Guid("5F3CAA13-F073-4F93-BDC2-B7F4B806CDAF");
#endregion SampleExternalResourceUIServer Member Variables
}
}
